Marshall DSL40C: 40W 2 Channel 1 x 12 Valve Combo



GENERAL
Model: DSL40
Range: DSL
Technology: Valve
Channels: 2 (Split) "Ultra gain" and "classic gain"

ELECTRONICS
Output wattage: 40w (with power reduction option to 20w)
Outputs: Speaker outputs - 5 x 1/4" jack sockets (16Ω load / 8Ω load / 4Ω load), 1 x 1/4" jack emulated line out
Inputs: 1 x 1/4" instrument jack, 1 x 3.5mm jack Aux in MIDI in, footswitch
Controls: Classic gain channel (gain, volume, clean crunch switch), ultra gain channel (gain, volume, OD1/OD2 switch), treble, middle, bass, tone shift switch, presence, resonance, reverb (classic gain channel), reverb (ultra gain channel), master select switch, master volume I, master volume II, loop on/off switch, low power option (on rear)
Effects: Digital reverb
Effects loop: Yes, series, send/return

SPEAKERS
Speaker configuration: 1x12"
Speaker model: Celestion V-Type speaker (16Ω, 80w)
Unit impedance: 16Ω

VALVES
Preamp valves: 4 x ECC83
Power amp valves: 2 x EL34

ACCESSORIES
Footswitch: PEDL-90012 included. Compatible with PEDL-91016 modes include: 1 - Clean (classic green) 2 - Crunch (classic red) 3 - OD1 (ultra green) 4 - OD2 (ultra red) 5 - Master 1/Master 2 (toggle) 6 - FX Loop on/off
Cable: Detachable power cable included
