Yamaha MG16 16-Channel D-Pre Mixer
The heart of the Yamaha MG16 lies in its exceptional D-Pre (Discrete Class-A Mic Preamps). These studio-grade preamps provide a solid foundation for your mix, delivering pristine audio with natural bass, soaring highs, and minimal distortion. The wide frequency range of the D-Pre preamps ensures that every element of your audio source is faithfully reproduced without any undue emphasis, saving you time on excessive EQing and processing.
The MG16 features high-quality sound op-amps developed in collaboration with leading semiconductor manufacturers. Emphasizing sound quality over all else, these custom-made MG01 op-amps optimize internal components and wiring, utilizing premium materials like high-quality silicon wafers and copper wire to achieve outstanding resolution. With 1-Knob Compressors, you can effortlessly shape your sound with optimized compression settings, elevating your guitars, bass lines, snares, and vocals with just a simple turn. The 3-band equalizers on all mono channels provide precise tone management, while the high-pass filters eliminate unwanted low-frequency noise, ensuring a clean and polished mix.
The MG16 is engineered for durability and reliability. Housed in a rugged, powder-coated metal chassis, this mixer can withstand the rigors of gigging, recording, and touring without compromising performance. The internal layout separates the power supply from the analogue circuitry, reducing noise and enhancing component lifespan. The XLR connectors lock securely to prevent accidental disconnection, ensuring stable signal transmission even in the most demanding environments.
At Riffs & Licks Music, we think that whether you're a live sound engineer, studio producer, or musician seeking to refine your sound, the Yamaha MG16 16-Channel D-Pre Mixer is an excellent choice, thanks to its outstanding features, professional sound quality, and rugged build.
Specifications
I/O | Phantom Power: +48V |
Input Channels | Mono[MIC/LINE]: 8 Mono/Stereo[MIC/LINE]: 2 Stereo[LINE]: 2 |
Output Channels | Stereo Out: 2 Monitor Out: 1 Phones: 1 Aux Send: 4 Group Out: 4 |
Bus | Stereo: 1 Group: 4 Aux: 4 |
Input Channel Function | Pad: 26dB (Mono) HPF: 80Hz, 12dB/oct (Mono) Comp: 1-knob compressor (Gain/Threshold/Ratio) Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB Attack time: approx. 25 msec, Release time: approx. 300 msec EQ High: (Mono) Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving EQ Mid: N/A EQ Low: (Mono) Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving Peak LED: LED turns on when post EQ signal reaches 3 dB below clipping Level Meter: 2x12 -segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB] |
Power Requirements | AC 100 – 240 V, 50 / 60 Hz |
Power Consumption | 30W |
Dimensions (W x H x D; mm) | 444 x 130 x 500 |
Net Weight | 6.6kg |
Accessories | Included Accessory: Owner’s Manual, Technical Specifications, AC power cord, Rack-mount kit |
(MG16AU)
SKU | MG16AU |
Model # | MG16//AU |
Barcode # | 4957812556323 |
Brand | Yamaha |
Shipping weight | 9.5000kg |
Shipping width | 0.523m |
Shipping height | 0.213m |
Shipping length | 0.559m |
Shipping cubic | 0.062272041m3 |
